Heating Plate (Glass-Ceramic)

IEH Series

Heating Plate (Glass Ceramic) IEH Series

Product Overview

IEH series heating plate (graphite) features a separate control unit and main heater connected by an aviation plug for remote operation. The main unit heats the graphite plate via mica heaters, while the PID controller ensure precise surface temperature regulation. Widely used in sample preparation and digestion, chemical synthesis, and general laboratory heating applications.
Features
  • LCD touchscreen with intuitive data display.
  • 10 programmable methods with custom naming.
  • Adjustable over-temperature protection and safety circuit.
  • 6-stage programming with real-time heating curves for multiple scenarios.
  • Nano-resin coating and titanium-plated insulation for corrosion resistance.
  • Multi-point temperature deviation compensation
  • Split-type design, effectively isolating the control components from the test environment.
  • Dual temperature probe monitoring.
  • Glass-ceramic heating surface : fast response, easy to clean.
  • Sealed 304 stainless steel body with corrosion resistance.
    •

    Product Parameters


    Model LCS-IEH50-1 LCS-IEH50-2 LCS-IEH50-3
    Power Supply AC220V 50Hz
    Total Power (W) 2500 3500 4500
    Circuit Breaker Rating / 25A 32A
    Display Mode LCD
    Temp. Control Range (°C) RT+20-500 RT+20-460
    Temp. Accuracy ±7%
    Controller Resolution (°C) 0.1
    Temp. Increment/Decrement (°C) 0.1
    Timing Range (min) 0～9999
    Heating Plate Dimension (mm) 400*280 450*350 600*400
    Plate Thickness (mm) 6
    Surface Material Glass-ceramic
    Max. Load Capacity (kg) 5
    Net Weight (kg) 11 13.8 18
    Product Dimensions (mm) 400x280x134 450x350x134 600x400x134
